48 × 36 × 36 corner-post crate
Plain 1/2" plywood walls screwed to 2x2 posts in the inside corners, with rails top and bottom, sitting on a pallet of 4x4 skids. Quick to build, nothing on the outside. Here's every part. Need a different size? Open it in Cratesmith and change any number, free.
- Outside
- 48" × 36" × 36"
- Inside
- 44-1/16" × 32-1/16" × 32-13/16"
- Parts
- 26
Cratesmith opens soon. Join the list and we'll send you the link on launch day.
Cut list
| Part | Qty | Name | Material | Size |
|---|---|---|---|---|
| A | 2 | Side panel1/2" plywood | 1/2" plywood | 48" × 34-13/16" |
| B | 2 | End panel1/2" plywood | 1/2" plywood | 35-1/16" × 34-13/16" |
| C | 1 | Floor panel1/2" plywood | 1/2" plywood | 47-1/16" × 35-1/16" |
| D | 1 | Lid panel1/2" plywood | 1/2" plywood | 48" × 36" |
| E | 4 | Corner post2x2 | 2x2 | 32-13/16" |
| F | 2 | Bottom rail, side2x2 | 2x2 | 44-1/16" |
| G | 2 | Bottom rail, end2x2 | 2x2 | 32-1/16" |
| H | 2 | Top rail, side2x2 | 2x2 | 47-1/16" |
| I | 2 | Top rail, end2x2 | 2x2 | 32-1/16" |
| J | 5 | Deck board1x4 | 1x4 | 36" |
| K | 3 | Skid4x4 | 4x4 | 48" |
How it goes together
- Build the pallet: deck boards across three 4x4 skids, then screw the floor panel down on top.
- Screw a corner post along each edge of the end panels, then stand them at the ends of the floor.
- Lap the side panels over the ends and screw into the floor edge and the posts.
- Fit the bottom and top rails inside, then screw the lid down into the top rails.
